Profiltyp - Standard
Offene Nuten - 4
Länge [Lmax] [mm] - 6070
Liefereinheit - 20
Profilfläche [A] [cm²] - 7.5
Widerstandsmoment in Y-Richtung [Wy] [cm³] - 6.1
Flächenträgheitsmoment in Y-Richtung [ly] [cm⁴] - 13.8
Torsionsträgheitsmoment [It] [cm⁴] - 2.65
Widerstandsmoment in X-Richtung [Wx] [cm³] - 6.1
Flächenträgheitsmoment in X-Richtung [lx] [cm⁴] - 13.8
Torsionswiderstandsmoment [Wt] [cm³] - 0.96
Masse [m] [kg] - 2
Gewicht [kg] - 248
