Nadelventil PNV series

Hebelaußen/inneninnen

Übersicht
Die Panam Nadelventile der Serie HP aus SS 316 sind in fünf Druckreihen (HP, HP1, HP2, HP3, HP6) für Hochdruck‑Flüssigkeits‑ und Gassysteme erhältlich. Gewindeoptionen: NPT, MP Cone und HP Cone. Gehäusekonfigurationen: gerade, Winkel, 3‑Wege und 2‑Stamm‑Manifold; austauschbare Sitze für Wartung.

Serien

• HP
• HP1
• HP2
• HP3
• HP6

Material

• SS 316

Druckstufen

• 10.000 psi (HP)
• 15.000 psi (HP1)
• 20.000 psi (HP2)
• 30.000 psi (HP3)
• 60.000 psi (HP6)

Gewinde- / Verbindungstypen

• NPT
• MP Cone
• HP Cone

Konfigurationen

• Gerade
• Winkel
• 3‑Wege (2 Eingänge / 2 Ausgänge)
• 2‑Stamm‑Manifold
• Austauschbarer Sitz

Produkt‑Tabelle (Part Number | Series | Pressure | Size | Connection Type | Configuration)
Part Number | Series | Pressure | Size | Connection Type | Configuration
PNV-HP-S-2NF | HP | 10,000 psi | 1/8" | NPT Female to Female | Straight
PNV-HP-S-4NF | HP | 10,000 psi | 1/4" | NPT Female to Female | Straight
PNV-HP-S-6NF | HP | 10,000 psi | 3/8" | NPT Female to Female | Straight
PNV-HP-S-8NF | HP | 10,000 psi | 1/2" | NPT Female to Female | Straight
PNV-HP-S-12NF | HP | 10,000 psi | 3/4" | NPT Female to Female | Straight
PNV-HP-S-16NF | HP | 10,000 psi | 1" | NPT Female to Female | Straight
PNV-HP-S-4NMF | HP | 10,000 psi | 1/4" | NPT Male x Female | Straight
PNV-HP-S-6NMF | HP | 10,000 psi | 3/8" | NPT Male x Female | Straight
PNV-HP-S-8NMF | HP | 10,000 psi | 1/2" | NPT Male x Female | Straight
PNV-HP-S-12NMF | HP | 10,000 psi | 3/4" | NPT Male x Female | Straight
PNV-HP-S-16NMF | HP | 10,000 psi | 1" | NPT Male x Female | Straight
PNV-HP-S-4NF-A | HP | 10,000 psi | 1/4" | NPT Female to Female | Angle Type
PNV-HP-S-6NF-A | HP | 10,000 psi | 3/8" | NPT Female to Female | Angle Type
PNV-HP-S-8NF-A | HP | 10,000 psi | 1/2" | NPT Female to Female | Angle Type
PNV-HP-S-12NF-A | HP | 10,000 psi | 3/4" | NPT Female to Female | Angle Type
PNV-HP-S-16NF-A | HP | 10,000 psi | 1" | NPT Female to Female | Angle Type
PNV-HP-S-4NMF-A | HP | 10,000 psi | 1/4" | NPT Male x Female | Angle Type
PNV-HP-S-6NMF-A | HP | 10,000 psi | 3/8" | NPT Male x Female | Angle Type
PNV-HP-S-8NMF-A | HP | 10,000 psi | 1/2" | NPT Male x Female | Angle Type
PNV-HP-S-12NMF-A | HP | 10,000 psi | 3/4" | NPT Male x Female | Angle Type
PNV-HP-S-16NMF-A | HP | 10,000 psi | 1" | NPT Male x Female | Angle Type
PNV-HP1-S-4NF | HP1 | 15,000 psi | 1/4" | NPT Female to Female | Straight
PNV-HP1-S-6NF | HP1 | 15,000 psi | 3/8" | NPT Female to Female | Straight
PNV-HP1-S-8NF | HP1 | 15,000 psi | 1/2" | NPT Female to Female | Straight
PNV-HP1-S-4NMF | HP1 | 15,000 psi | 1/4" | NPT Male x Female | Straight
PNV-HP1-S-6NMF | HP1 | 15,000 psi | 3/8" | NPT Male x Female | Straight
PNV-HP1-S-8NMF | HP1 | 15,000 psi | 1/2" | NPT Male x Female | Straight
PNV-HP1-S-4NMF-A | HP1 | 15,000 psi | 1/4" | NPT Male x Female | Angle Type
PNV-HP1-S-6NMF-A | HP1 | 15,000 psi | 3/8" | NPT Male x Female | Angle Type
PNV-HP1-S-8NMF-A | HP1 | 15,000 psi | 1/2" | NPT Male x Female | Angle Type

Hinweise
Es stehen 103 Konfigurationen in der HP‑Familie zur Verfügung, die mehrere Größen, Verbindungstypen (NPT, MP Cone, HP Cone), Gehäusekonfigurationen (gerade, Winkel), Mehrfachanschluss‑Optionen (3‑Wege) und Manifold‑Optionen sowie austauschbare Sitze abdecken. Die obige Tabelle listet repräsentative Artikelnummern und Konfigurationen.
