Elektrohydraulisches Hebegerät FP PS 04 E series

batteriebetriebenmanuellGabel

Battery lifter for boxes and reels FP PS 04 E - Capacity 400 kg Lifter with manual pushing and lifting with electrohydraulic pump, allows lifting loads (axle, bags, containers, mini pallets, etc.) with a maximum weight of 400 kg up to a height of 1510 mm. The FP PS 04 E lift is compact and easy to handle. Equipped with large diameter polyurethane wheels for smooth running (two fixed and two swivel, complete with brake). Delivery includes forks with a length of 650 mm.The 12 V-80 Ah maintenance-free battery, combined with the robust motor and control electronics with overload protection, ensures safe and reliable operation. The battery charger is integrated.ModelMOD. FP PS 04 E Capacity loadKg. 400Min. height from floormm. 90Max. lifting heightmm. 1510Fork lengthmm. 650Outer fork widthmm. 550Single fork widthmm. 105Inner fork widthmm. 340Center of gravitymm. 325Lifting speedmm. 135 / sec.Lowering speed12 sec.Battery12 V. – 80 Ah.Built-in charger220 V.Motor powerKw. 0.8Machine dimensionsmm. 580 x 1090 x 1730 h.Height of wheel framemm. 80 (can be inserted under the pallet)Fixed wheel diametermm. 75Steering wheel diametermm. 125WeightKg. 127Lifter with forks.The load must be evenly distributed on the forks.As with all lifting devices, attention must be paid to the safety diagram.Depending on the size and characteristics of the lift, the capacity decreases with increasing height or distance from the center of gravity.The products are very robust and mechanically simple.It is rare for them to have problems. In case of need, we have all spare parts in stock.All models are CE certified and are supplied with a specific user and maintenance manual.No special license is required to use the lift.The operator must be trained and informed. It is necessary that the instructions in the manual are read and followed.OPTIONAL:ACC-PZ galvanized steel platform:Galvanized steel platform that can be placed over the forks. Platform dimensions mm 580x650 - load capacity 400 kg.ACC-PN-VRP lowered V-platform for reels – parallel:Allows horizontal lifting and transport of reels with max. width 600 mm and max. weight 100 kg - parallel to the direction of travel of the trolley.ACC-PN-V1/2 V-platform for reels – parallel or perpendicular (as chosen):Allows horizontal lifting and transport of reels with max. width 600 mm and max. weight 150 kg – parallel or perpendicular to the direction of travel of the trolley.ACC-APF1 fixed reel holder shaft:Diameter 50 mm and length 600 mm, allows gripping and horizontal transport of reels with max. width 600 mm and max. weight 150 kg. The fixed reel holder shaft is not interchangeable with other available parts (e.g. V-shaped platform for reels). Choosing the fixed reel holder shaft removes the two front forks and the metal plate from the elevator.ACC-APF2 fixed reel shaft + extended supports:Diameter 60 mm and length 1000 mm, allows gripping and horizontal transport of reels with max. width 600 mm and max. weight 100 kg. The fixed reel shaft is not interchangeable with other available parts (e.g. V-shaped platform for reels). Choosing the fixed reel shaft removes the two front forks and the metal plate from the elevator. This modification includes the extension of the front supports of the trolley for safe use.ACC-PGN1 pin with hook version 1:Pin with hook load 100 kg and max. lifting height at the hook 1800 mm – max. distance from the post 600 mm. The pin with hook is not interchangeable with other available accessories (e.g. V-platform for reels). Choosing the pin with hook with a capacity of 100 kg removes the two front forks and the metal surface from the lifter.ACC-PGN2 pin with hook version 2:Pin with hook load 200 kg and max. lifting height at the hook 1600 mm – max. distance from the post 450 mm. The pin with hook is not interchangeable with other available accessories (e.g. V-platform for reels). Choosing the pin with hook with a capacity of 200 kg removes the two front forks and the metal surface from the lifter.Double fixed reel holder pinDouble fixed pin for reels with a maximum width of 600 mm. Ideal for lifting and loading reels into machines. Maximum load capacity 80 kg. The double fixed pin is not interchangeable with other available accessories (e.g. V-shaped platform for reels). Choosing the double fixed pin removes the two front forks and the metal surface from the lifter.All models are CE certified and supplied with a specific user and maintenance manual.No special license is required to use the lift.The operator must be trained and informed. It is necessary that the instructions in the manual are read and followed.Technical Specifications:Model: FP PS 04 ECapacity: 400 kgMin. height from floor: 90 mmMax. lifting height: 1510 mmFork length: 650 mmOuter fork width: 550 mmSingle fork width: 105 mmInner fork width: 340 mmCenter of gravity: 325 mmLifting speed: 135 mm/secLowering speed: 12 secBattery: 12 V – 80 AhBuilt-in charger: 220 VMotor power: 0.8 kWMachine dimensions: 580 x 1090 x 1730 mm (h)Height of wheel frame: 80 mm (can be inserted under the pallet)Fixed wheel diameter: 75 mmSteering wheel diameter: 125 mmWeight: 127 kg
