Druckkopf – Flachkopf
Abmessungen – 278 x 460 x 310 mm (B x T x H)
Gewicht – 17 kg
Schnittstellen – USB 2.0, Ethernet
Optionale Schnittstellen – Serielle Schnittstelle, Parallele Schnittstelle, Erweiterungs-E/A-Schnittstelle, RTC- und USB-
Host-Schnittstelle, WLAN-Schnittstelle
Netzwerk-Tool – SNMP
Speicher – 64 MB (FROM), 32 MB (SRAM)
Schriftart – Bitmap, Kontur, beschreibbare Zeichen, optional TrueType
Barcode – UPC/EAN/JAN, Code 39, Code 93, Code 128, EAN 128, NW7, MSI, Interleaved 2 of
5, Industrial 2 of 5, Matrix 2 of 5, Postnet, RM4SCC, KIX-Code, kundenspezifischer Barcode, GS1
Databar
2D-Codes – Data Matrix, PDF417, MaxiCode, QR-Code, Micro PDF417, CP-Code, AZTEC-Code,
GS1-QR-Code
MEDIEN
Papierbreite – 25 mm – 110 mm
Papierausrichtung – zentriert
Papierrolle – 200 mm (7,9")
FARBBAND
Farbbandtyp – Spulentyp
Maximale Farbbandbreite – 115 mm
Maximale Farbbandlänge – 300 mm
SOFTWARE & KONNEKTIVITÄT
Druckertreiber – Windows 10/8.1 (32/64 Bit), Windows Server 2016, Windows Server 2012
R2/Windows Server 2012, SAP
Sprachmodus – TPCL, Basic Command Interpreter
---
