Vertikales Umlaufregal

für Rohrefür TextilienTextilrollen

Product Details: - Type: Rotating storage – Automatic vertical carousel for rolls and bobbins Applications: - Soft floor coverings - Technical fabrics (fiberglass, tarpaulins, coated fabrics, etc.) - Packing rolls/packaging Storage Method: - On an axle adapted to the inner diameter of your core – the appropriate axle diameter is determined by load calculation to prevent bending. - The material can be pulled directly from the rotating carousel by a textile cutting machine or general cutting machine, or placed on a simple table for final cutting and padding. - The position of the axles is adjustable on the conveyor chain, offering high flexibility for warehouse optimization. - Available as a single loop or multiple consecutive loops, depending on the total load. Versions and Accessories (depending on configuration): - Centering cone - Guide flange - Mounted axle - Retaining straps - Label holder - Cycle start/end variator (depending on total load) - Cell barrier - Double forward/reverse control - Manual or automatic cutting table - Measuring system - Unwinding frame - Roll reel on wheels, crank drum type - etc. Loading / Unloading: - With a suitable transport trolley, allowing ergonomic loading at the lower level - Various types of trolleys available, including manually operated battery-powered loading trolleys Technical Data: - 13 available device heights - 5 assortments available depending on max. diameter - 3 types of conveyor chains - Maximum weight: 1000 kg - Max. diameter: 980 mm - Total length: from 2 m to 6.5 m - Linear speed: between 4 and 6.10 m/min maximum - Control: continuous or automated operation - Power supply: 220V or 380V – from 0.55kW to 1.5kW Specification Sheet Components: - Outer diameter of the roll - Inner diameter of the roll - Maximum width - Maximum weight - Quantity to be stored - Applicable with single or double access - Available height - Delivery of a manual or automatic cutting table - Control with continuous operation or via PLC - Possible other constraints (ATEX zone, power supply, etc.) Key Features: - Easy operation: Standard control mode in continuous operation allows access to the desired item. Usable in both rotation directions. - Operational safety: No risk for your employees, ergonomic working height for loading and unloading. - Fast access: Quickly obtain the desired reference in continuous operation or via an automated device with item code visualization. - Optimal use of space: Easily utilize the height of your building. - Inventory control: Quick inventory of your stocks – for optimized management, E.R.P/W.M.S integration possible. - Storage of heavy and bulky products: Special solutions for every application.
