Analoges Telefon

IP66für Aufzügefür Tunnel

Model
Five way intercom with Master

Introduction
The elevator Intercom system will be applied to elevator emergency or maintenance application. Also applicable for shipping center, bus terminal, car park center, tunnel construction, etc.
Power supply: Centralized DC 12V or AC 110~220V AC

Operating Instructions

• Master station call elevator phone: Pick up the master station handset, press the elevator phone number and speak to it. Press * to speak all elevator phone. Elevator phone will auto stop when master station hang up.
• Elevator phone call Master station: press call button or pick up hand, the phone will automatically call master station. Both master will ring. Elevator phone will auto stop when master station hang up.
• Master1 call Master2: Pick up the handset of the Master1, then press the other master station phone number, Master2 rings, speak to it.

Specification (as listed)
Working Voltage: DC12V
Operating Current: ??300mA
Maximum Power Consumption: 2W
Noise Voltage: ??1OmV
Communication Distance: ??2000m
Ringing Level:??7OdB

Working Condition
- Ambient Temperature: -40????60??; Relative Humidity: 30%??95%
- Ambient Noise: 60 dB; Line Number: double core line
- Description for the wire: single line resistance can't more than 50 Ohm.

Wire requirements
Require all connecting the kingdom line, multicore parallel lines can meet the general engineering requirements. When walking line and strong power line interference serious environmental mixed wiring, the shielding measures should be adopted to keep distance and take more than 30 cm.

CERTIFICATION
EN50121 (Railway application - Electromagnetic Compatibility)
EN55022: emissions
EN55024: immunity
Ingress Protection: GB4208-93 IP66
FCC
ITU-T Recommendations K21

Packing details
1 pcs in each inner CTN box, size: 43.3 x 27.6 x 19.1; G.W: 4kg
4 pcs in outer CTN box, size: 56.6 x 44.5 x 42; G.W: 20.25kg
20GP: 3000 PCS; 40GP: 6000 PCS; 40HQ: 7000 PCS

Caractéristiques / spécifications techniques

• Modèle: Five way intercom with Master
• Alimentation: Centralized DC 12V or AC 110~220V AC
• Tension de fonctionnement: DC12V
• Courant de fonctionnement: ??300mA
• Consommation maximale: 2W
• Tension de bruit: ??1OmV
• Distance de communication: ??2000m
• Niveau de sonnerie: ??7OdB
• Conditions de fonctionnement: Température ambiante -40????60??; Humidité relative 30%??95%
• Bruit ambiant admissible: 60 dB
• Type de ligne: double core line (la résistance d'une ligne ne doit pas dépasser 50 Ohm)
• Exigences de câblage: éviter le croisement avec lignes de puissance; mettre blindage et garder >30 cm en cas d'interférences
• Certifications principales: EN50121, EN55022, EN55024, GB4208-93 IP66, FCC, ITU-T K21
• Détails d'emballage: 1 pc/CTN intérieur (43.3 x 27.6 x 19.1, 4kg); 4 pcs/CTN extérieur (56.6 x 44.5 x 42, 20.25kg); capacités conteneur: 20GP 3000pcs, 40GP 6000pcs, 40HQ 7000pcs
