Cutter mit Trapezklinge E series

Horizontal cutters of the E series Universal cutter for paper, corrugated cardboard, papers and polyethylene-reinforced polyethylene film, polyethylene bubble wrap up to 6 mm thick. The use of the cutting device is extremely simple: after unwinding the material to the desired length by manually operating the carriage, you obtain a clean and precise cut in both directions with the blade. All cutting devices are mounted on swivel castors with brakes. For space reasons, the product is shipped disassembled. - Model: 100 E, 140 E, 160 E, 200 E, 250 ER - Max. cutting width in cm: 100, 140, 160, 200, 250 - Blade type: Trapezoidal (standard) for cutting plastic films - Load: Kg 50 (Kg 100 with option), Kg 100 for 250 ER - Max. roll diameter: cm 100 - Cutter size (cm): Width 118/158/178/218/268, Depth 80, Height 115 - Weight kg: 22/26/28/30/36 The cutter is supplied complete with the CUTTING GROUP MODEL A, equipped with trapezoidal blades for paper, corrugated cardboard, plastic films such as reinforced polyethylene, bubble wrap and foam. OPTIONAL REINFORCED SUPPORT When ordering, it is possible to request the cutter with a load capacity for rolls up to 100 kg by selecting the option in the accessories and paying a surcharge. - Universal cutter for paper, cardboard, polyethylene film, bubble wrap, and foam up to 6 mm thick - Manual operation for precise bidirectional cutting - Mounted on swivel castors with brakes - Delivered disassembled for space-saving shipping - Standard trapezoidal blade for plastic films - Optional reinforced support for up to 100 kg rolls - Supplied with cutting group model A
