Heißluftsiegelmaschine FP SM-A series

halbautomatischfür Lebensmittelfür Thermostat

Semi-automatic heat sealing machines for sealing pre-formed trays – FP SM-A series The semi-automatic heat sealing machines FP SM-A are suitable for packaging food in pre-formed trays with plastic sealing film made of PP, PET, PS, PE. They are ideal for delicatessens, supermarkets, grocery stores, craft businesses, and the catering industry. All machines are made of stainless steel and anodized aluminum. The workflow is time-controlled and electrically operated; functions are managed via the digital control panel. Standard machines operate with 220V power supply, models with 120V are available on request. MODELS AND APPROXIMATE PRICES The three models listed on this page can seal plastic film on trays of different sizes depending on the installed mold. The indicated price includes the heat sealing machine and 1 fixed standard mold with 1 hole. On request, we are happy to provide a quote for the heat sealing machine equipped with special molds and various accessories. OPERATION: The operator must position the tray in the mold and insert the mold into the heat sealing machine. The machine then automatically seals the film onto the tray. At the end of the cycle, the operator is notified by an acoustic signal, and once the mold is removed, the sealed trays can be taken out. In this series of heat sealing machines, the film is sealed onto the tray but not cut. If a film wider than the tray is used, the operator must finish the job by manually trimming it. AVAILABLE MODELS: FP SM-101A: Semi-automatic heat sealing machine for trays with maximum dimensions 205 x 150 x 100 mm FP SM-102A: Semi-automatic heat sealing machine for trays with maximum dimensions 260 x 195 x 155 mm FP SM-105A: Semi-automatic heat sealing machine for trays with maximum dimensions 370 x 280 x 155 mm Considering the above measurements, it is possible to create molds for multiple trays. For example, with the FPSM105A model, it is possible to create up to 4/6 holes in the mold and seal 4/6 trays at the same time. MODEL FP SM-101A FP SM-102A FP SM-105A Dimensions 240x390 h. 500 mm 295x450 h. 555 mm 460x510 h. 555 Voltage 220 V 220 V 220 V Power 550 W 700 W 1400 W Weight 20 Kg 25 Kg 35 Kg Max. roll dimensions L=150 Diameter 160 mm L=210 Diameter 200 mm L=380 Diameter 200 mm Max. tray dimensions 205x150 mm 260x195 mm 370x280 mm Max. tray depth 100 mm 155 mm 155 mm Customizable sealing programs 9 9 9 Cycles per minute 6-8 6-8 6-8 Machine features: Designed for packaging in pre-formed trays of various sizes with compatible sealing films. Made of stainless steel and anodized aluminum. Teflon-coated aluminum sealing plate. Nine storable welding programs. Electronic control of the sealing plate temperature (0-200°C). Acoustic and luminous warning signal at the end of the cycle. Automatic motorized sealing, powered only by electricity. The sealing cycle is automatically activated when the mold is fully inserted. Quick and easy format change. The cover film roll is placed over the front of the machine and unwinding is automatic when the mold is manually inserted. USABLE MOLDS: The manual heat sealing machines can use two different types of molds, the "adjustable" and the fixed, non-punched molds: FPSM-101A FPSM-102A FPSM-105A - Adjustable type 1- Fixed with 1 hole- Fixed with 2 holes - Adjustable type 1- Adjustable type 2- Adjustable Plus type- Fixed with 1 hole- Fixed with 2 holes- Fixed with 4 holes - Adjustable type 1 double – 2 trays- Adjustable type 2- Adjustable type 2 Plus- Fixed with 1 hole- Fixed with 2 holes- Fixed with 4 holes- Fixed with 6 holes While the "fixed molds" are specifically tailored to the size of the trays, the adjustable molds can be adapted to different tray sizes. The "adjustable" molds are available in the following versions: - Type 1: suitable for sealing trays of sizes mm. 190x137 - 137x125 - 137x95 - Type 2: suitable for sealing trays of sizes mm. 260x190 - 230x190 - 190x137 - 137x95 - Plus type: suitable for sealing trays of sizes mm. 260x190 - 230x190 - 190x137 - 137x125 - 137x95 - Type 1-double: suitable for sealing 2 trays of sizes mm. 190x137 - 137x125 - 137x95 HEAT SEALING FILM: The film for heat sealing machines is available in the following materials: PET-PP: for polypropylene trays for microwave cooking PET-PE: for polypropylene and cardboard trays Melinex: for cardboard trays for traditional oven and microwave cooking OPTIONAL - Drilling unit: Ideal for creating a series of holes in the film so the product in the tray can breathe - Front cutter for separating the center film between two compartments (only models FP SM-102A / FP SM-105A) - Film guard to protect the film roll from dirt and contamination (only model FP SM-102A) - Carbon-nitrogen washing system (only models FP SM-102A / FP SM-105A) The FP SM-102/105A models can be equipped with the tray washing system. This option introduces nitrogen/carbon into the tank, washes it, and extends the product shelf life. Designed for packaging food in pre-formed trays with plastic sealing film (PP, PET, PS, PE)Ideal for delicatessens, supermarkets, grocery stores, craft businesses, and cateringMade of stainless steel and anodized aluminumTime-controlled and electrically operated workflowDigital control panelStandard 220V power supply (120V on request)Three models: FP SM-101A, FP SM-102A, FP SM-105ASealing film is not cut automaticallyCustomizable molds for multiple traysQuick format changeAutomatic motorized sealingElectronic temperature control (0-200°C)Acoustic and luminous end-of-cycle signalUp to 6-8 cycles per minuteOptional: drilling unit, front cutter, film guard, carbon-nitrogen washing system
