Lüfterlos, stromsparend, DinRail-Montage & Unterstützung einer Mini-Card für Wireless-Module
Anwendungen:
Thin Client、Home Automation、Digital Signage、Transportwesen、Motion Automation、Fahrzeug Computer
Optionales Zubehör:
FX5311K1 - VESA-Halterung (nur 75 x75 mm)
FX5321K1 - 2U-Rack-Montage
AK-1006 - Adapterkit für PCIe-Mini-Karten halber Größe
FX5407K3 - LCD-VESA-Montage-Kit
Funktionselemente - Spezifikationen
CPU-Karte - Atom N2600 + NM10
Prozessor - Atom N2600 1.6GHz
DRAM - 2GB DDR3
DRAM-Sockel - 204-Pin SoDIMM *1 (DDR3, maximal 2GB)
E/A-Anschluss - -
KB/Maus - -
Seriell - RS232/422/485 *1、RS232/422/485/CANBUS*1
Parallel - -
USB - 4 (2.0)
LAN - 2 (Giga LAN)
Anzeige - VGA
Doppelanzeige - -
Audio - Ja
GPIO - 2 Eingänge、2 Ausgänge
BUS I/F - PCIe Mini-Kartensteckplatz *1
Speicherschacht -
CFast-Sockel - Ja
SD-Steckplatz - Ja
Festplattenplatz - 2,5" *1 (SATA)
Stromversorgung -
Eingangsspannung - DC 9~32V
Nennstrom - 35VA Max
Betriebssystem - Windows XPe / 7, und Linux
Betriebstemperatur - 0℃ bis 50℃ (32℉ bis 122℉)
Konformitäten - CE / FCC / RoHS
Abmessungen (B x T x H) - 50 x 102 x 145 mm
---
