Steckverbinder Kupplung, M12x1, axial Stecker, M12x1, axial
Polzahl 5 5
Codierung A A
Bemessungsspannung
60V
60V
Strombelastbarkeit pro Pin (bei 40°C) 4 A 4 A
Isolationswiderstand
≥108 Ω
≥108 Ω
Durchgangswiderstand mΩ mΩ
Umgebungstemperatur -30°C...+90°C -30°C...+90°C
Material Kontakte Metall, CuZn, vergoldet Metall, CuZn, vergoldet
Material Kontaktträger Kunststoff, TPU, YE Kunststoff, TPU, YE
Normen IEC 61076-2-101 IEC 61076-2-101
Schutzart (montiert) IP67 IP67
Mechanische Lebensdauer >100 Steckzyklen >100 Steckzyklen
Verschmutzungsgrad 3 3
