MIG-MAG-Schweißbrenner ERGOFLOW 240

luftgekühltRauchabzugmanuell

240 Manuelle Absaugbrenner ERGOFLOW MIG/MAG

ENGMAR offers a complete range of MIG/MAG fume extraction welding torches, from 180 to 500 A, available in both air and water cooled versions. ERGOFLOW torches are notable for their ability to capture up to 98% of welding fumes, effectively protecting operators and maintaining workshop air quality.ENGMAR offers a complete range of MIG/MAG fume extraction welding torches, from 180 to 500 A, available in both air and water cooled versions. ERGOFLOW torches are notable for their ability to capture up to 98% of welding fumes, effectively protecting operators and maintaining workshop air quality.

With a wide selection of extractors and gooseneck angles, combined with an especially flexible cable assembly, ENGMAR torches deliver optimal ergonomics and efficient fume capture, even during intensive work or in hard-to-reach areas.

Several control modules are available to meet every need, including extraction shut-off, multiple buttons, or a decompression valve.


Eigenschaften:

• Leistung 180 A (gasgemisch)
• 220 A (CO2)
• Einschaltdauer: 60%
• Empfohlene Drahtdurchmesser: 0.8 - 1.2 mm
• Erhältich in 50°

Vorteile:

• Maximale Anpassungsfähigkeit dank verschiedener Brennerwinkel (45°, 50°, 60°)
• VerstäLange Lebensdauer durch Lederummantelung brennerseitig
• Ergonomische Handhabung und hohe Manövrierfähigkeit
• Schnelle, zuverlässige Verbindung mit europäischem Monoblock-Stecker
• Individuell anpassbare Brenner mit Auswahl an Brennerköpfen und Steuerungsoptionen (Ventil, Tasten)

Normenkonformität
EN 21904-1
EN 21904-4
EN 60974
