Laser-Laufzeitmessung-Abstandssensor Dilas FT1800

Profibusfür raue Umgebungenkompakt

- Digital communication: Profibus-DP, Profinet, Ethernet Modbus TCP, EtherNet/IP - High temperature targets - Long range - High accuracy - Easy setup and installation - Design for difficult conditions The Dilas FT1800 is a digital, high resolution, non-contact laser distance measurement or detection sensor. The target may be hot or cold, stationary or moving. Dilas FT1800 measures on all non-shiny surfaces. The operation of the Dilas FT1800 is based on time-of-flight measurement. The sensor calculates the distance of the target surface using the time of flight of visible laser light pulses. Presentation : The Dilas FT1800 is an autonomous sensor mounted in compact aluminium housing, IP66. The sensor can be ordered with mounting bracket or mounting stand and water-cooling jacket. A digital display indicates the measured distance and two LED indicate status of sensor. For the models with digital communication, two additional LED indicate the communication link status. The sensor can work as a standalone unit: in that case, the setup is made from the control panel at the back of sensor.
